    WGB-090 CuSn8P Self Lubricating Rolled Bronze Wrapped Bearings

    Ask Lasest Price
    Brand Name : OEM
    Model Number : FB090
    Supply Ability : 1000000 Piece/ per Month
    Price : Negotiation
    Delivery Time : 10-15 working days
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    • Product Details
    • Company Profile

    WGB-090 CuSn8P Self Lubricating Rolled Bronze Wrapped Bearings

    WGB-090 CuSn8P Self Lubricating Rolled Bronze Wrapped Bearings

    Product Description
    Product NameWGB-090 Bronze Warpped Bearings
    MaterialCuSn8/CuSn6.5P0.1
    StandardISO3547 (DIN1494)
    Characterstics

    · WGB-090 Bronze Warpped Bearings offer good wear and low friction performance over a wide range of loads, speeds and temperatures
    · good performance in lubricated applications
    ·Very Good performance in greased applications
    ·Suitable for linear, oscillating and rotating movements
    WGB-090 Bronze self-lubricating bearings used a kind of high density broze alloy of special compositions as base, surface of alloy is rolled diamond type of the oil indents or half ball oil indents, this kind of bearing has higher density, load capacity, well wearing performance, longer lifetime. It has been widely used in many fields, such as hoist machines, building machinery, machine tool industry and mining machinery.
    Technical Date
    Maximum loadStatic loadN/mm²120
    Dynamic loadN/mm²40
    Operating temperatureMinimal-40
    Max greased150
    Max oil lubricated250
    Grease/Oil lubricatedMaximum sliding speedm/s2.5
    Maximum PV factorN/mm²·m/s2.8
    Coefficient of friction0.06-0.15
